Located in Chennai, India, we proudly stand as a top manufacturer and supplier of **90° Long Radius Elbow** fittings. Our products are crafted with precision to facilitate a smooth 90-degree change in flow direction. These elbows are essential in industrial piping systems where minimizing friction loss and ensuring a seamless flow transition are crucial. We adhere to international standards like ASME B16.9 and ASTM specifications, offering our long radius elbows in a variety of materials, including stainless steel, carbon steel, alloy steel, and special alloys, tailored to meet different pressure and temperature requirements.

90 Deg Long Redius Elbow Price List in Chennai, Stainless Steel 90 Deg Long Redius Elbow Supplier in India, ANSI/ASME B16.9 90 Deg Long Redius Elbow Exporter in Chennai, SS 90 Deg Long Redius Elbow Supplier in Chennai, Carbon Steel 90 Deg Long Redius Elbow Exporter in Chennai, Alloy Steel ASME B16.25 90 Deg Long Redius Elbow Size Chart, ANSI B19.28 90 Deg Long Redius Elbow Price in India, MSS-SP-43 90 Deg Long Redius Elbow in Chennai, Duplex Steel 90 Deg Long Redius Elbow Supplier in Chennai, Nickel Alloy 90 Deg Long Redius Elbow Stockist in India, Low Temperature Carbon Steel 90 Deg Long Redius Elbow Exporter in India

90 Deg Long Redius Elbow Specification

Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.

DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

EN : EN10253-1, EN10253-2

Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Type : Seamless / ERW / Welded / Fabricated

Seamless 90° Long Radius Elbow Size: 1/2″~24″

ERW / Welded / Fabricated 90° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)

Form: 90° Long Radius Elbow

The **90° Long Radius Elbow** fittings feature a center-to-end distance that is 1.5 times the nominal diameter of the pipe (R = 1.5D), allowing for a gentle directional shift that helps reduce pressure drop and turbulence. Available in both seamless and welded options, these elbows come in various sizes, thicknesses, and pressure ratings. Depending on the material, they provide excellent corrosion resistance, high mechanical strength, and good weldability, ensuring they deliver long-lasting, leak-proof performance.

90 Deg Long Redius Elbow Material & Grades

Stainless Steel 90° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Carbon Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Alloy Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91

Duplex Steel 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205

Super Duplex 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950

Nickel Alloy 90° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.

Low Temperature Carbon Steel 90° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6

Low Temperature Carbon Steel 90 Deg Long Redius Elbow Exporter in India, 90 Deg Long Redius Elbow Price List in Chennai, Stainless Steel 90 Deg Long Redius Elbow Supplier in India, ANSI/ASME B16.9 90 Deg Long Redius Elbow Exporter in Chennai, Alloy Steel 90 Deg Long Redius Elbow Exporter in Chennai, ASME B16.9 90 Deg Long Redius Elbow in India, MSS-SP-43 90 Deg Long Redius Elbow Size Chart, Alloy Steel ASME B16.25 Price in India, Pipe Fittings 90 Deg Long Redius Elbow Manufacturer Weight Chart, Fitting 90 Deg Long Redius Elbow Supplier in Chennai, Stainless Steel 90 Deg Long Redius Elbow Stockist in India.

Largest 90 Deg Long Redius Elbow Supplier in Chennai, India

Meet Fittings is a leading supplier of 90 Deg Long Redius Elbow in Chennai, India. We offer an extensive range of 90 Deg Long Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose 90 Deg Long Redius Elbow from Meet Fittings?

Choose 90 Deg Long Redius Elbow from Meet Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

Stainless Steel 90 Deg Long Redius Elbow Exporter in India, Carbon Steel 90 Deg Long Redius Elbow in mm, Alloy Steel 90 Deg Long Redius Elbow Manufacturer in Chennai, Super Duplex 90 Deg Long Redius Elbow in Chennai, Nickel Alloy 90 Deg Long Redius Elbow, Low Temperature Carbon Steel 90 Deg Long Redius Elbow Supplier in Chennai, ANSI/ASME B16.9 90 Deg Long Redius Elbow Price List in Chennai, SS 90 Deg Long Redius Elbow Distributor in Chennai, Alloy Steel ASME B16.25 90 Deg Long Redius Elbow Supplier in Chennai, Pipe Fittings 90 Deg Long Redius Elbow Distributor in India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

90° Long Radius Elbows offer several advantages, including smooth directional changes in piping systems that minimize turbulence and reduce pressure loss. The long radius design ensures a more gradual bend, which helps maintain flow efficiency and reduces the likelihood of erosion or wear on the pipe. Made from durable materials like stainless steel and alloys, these elbows provide excellent resistance to corrosion and high-pressure environments. They are ideal for industries such as oil and gas, chemical processing, and water treatment, ensuring long-term reliability, durability, and enhanced system performance.

Types of 90 Deg Long Redius Elbow

Are Custom Sizes Available for 90 Deg Long Redius Elbow?

Yes, custom sizes for 90 Deg Long Redius Elbow are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.

Are Custom Sizes Available for 90 Deg Long Redius Elbow?

LONG RADIUS ELBOWS (R = 1,5 ND) ANSI B 16.9 dimensions
inches	ND	mm	Center to center	Radius	Center to end	Back to face
D			O	A	B	K
1/2	15	21,34	76,20	38,10	15,87	47,62
3/4	20	26,67	57,15	28,57	11,11	42,86
1	25	33,40	76,20	38,10	22,22	55,56
1 1/4	32	42,16	95,25	47,60	25,40	69,85
1 1/2	40	48,26	114,30	57,15	28,57	82,55
2	50	60,32	152,40	76,20	34,92	106,40
2 1/2	65	73,02	190,50	95,25	44,45	131,80
3	80	88,90	228,60	114,30	50,80	158,75
3 1/2	90	101,60	266,70	133,35	57,15	184,15
4	100	114,30	304,80	152,40	63,50	209,55
5	125	141,30	381,00	190,50	79,38	261,90
6	150	168,27	457,20	228,60	95,25	312,70
8	200	219,07	609,60	304,80	127,00	414,30
10	250	273,05	762,00	381,00	158,75	517,50
12	300	323,85	914,40	457,20	190,50	619,10
14	350	355,60	1066,80	533,40	222,25	711,20
16	400	406,40	1219,20	609,60	254,00	812,80
18	450	457,20	1371,60	685,80	285,74	914,40
20	500	508,00	1524,00	762,00	317,50	1016,00
22	550	558,80	1676,40	838,20	342,90	1117,60
24	600	609,60	1828,80	914,40	381,00	1219,20
28	700	711,20	2133,60	1066,80	441,90	1422,40
Dimensions in mm.

90 Deg Long Redius Elbow Supplier in Chennai, Stainless Steel 90 Deg Long Redius Elbow Weight Chart, Carbon Steel 90 Deg Long Redius Elbow Exporter in India, Alloy Steel 90 Deg Long Redius Elbow Manufacturer in Chennai, Duplex Steel 90 Deg Long Redius Elbow Price List in Chennai, Super Duplex 90 Deg Long Redius Elbow Sizes in mm, Nickel Alloy 90 Deg Long Redius Elbow Distributor in Chennai, Low Temperature Carbon Steel 90 Deg Long Redius Elbow Distributor in India.

Application Industry of 90 Deg Long Redius Elbow

You’ll find the **90° Long Radius Elbow** widely used in applications such as oil and gas pipelines, power plants, chemical processing facilities, water treatment systems, and HVAC piping. Its smooth curvature enhances flow characteristics, making it perfect for systems that demand minimal pressure loss and improved flow efficiency. These elbows are suitable for both above-ground and underground installations, performing reliably even under high pressure and temperature. The 90° long radius elbow is an essential component for creating efficient and durable piping systems across a broad spectrum of industrial sectors.
