90 Deg Short Redius Elbow Manufacturer and Supplier in Chennai, India
Based in Chennai, India, we take pride in being a well-respected manufacturer and supplier of **90° Short Radius Elbow** fittings. Our products are crafted to provide reliable, high-quality solutions for changing the direction of flow in piping systems by 90 degrees, even in tight spaces. These elbows feature a center-to-end distance that matches the pipe’s nominal diameter, making them perfect for applications where every inch counts. We adhere to international standards like ASME B16.9, and our short radius elbows come in a range of materials, including stainless steel, alloy steel, carbon steel, and special alloys.
Table of Contents
90 Deg Short Redius Elbow Price List in Chennai, Stainless Steel 90 Deg Short Redius Elbow Supplier in India, ANSI/ASME B16.9 90 Deg Short Redius Elbow Exporter in Chennai, SS 90 Deg Short Redius Elbow Supplier in Chennai, Carbon Steel 90 Deg Short Redius Elbow Exporter in Chennai, Alloy Steel ASME B16.25 90 Deg Short Redius Elbow Size Chart, ANSI B19.28 90 Deg Short Redius Elbow Price in India, MSS-SP-43 90 Deg Short Redius Elbow in Chennai, Duplex Steel 90 Deg Short Redius Elbow Supplier in Chennai, Nickel Alloy 90 Deg Short Redius Elbow Stockist in India, Low Temperature Carbon Steel 90 Deg Short Redius Elbow Exporter in India
90 Deg Short Redius Elbow Specification
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe 90° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Short Radius Elbow
Our **90° Short Radius Elbow** fittings are designed with a radius that equals the nominal diameter of the pipe (R = 1.0D), unlike long radius elbows (R = 1.5D). This design creates a more compact fitting with a sharper turn, making it ideal for high-turbulence flow situations. We can produce these elbows in both seamless and welded forms, and they come in various sizes and pressure classes. Depending on the material, they offer excellent dimensional accuracy, weldability, and resistance to corrosion.
90 Deg Short Redius Elbow Material & Grades
Stainless Steel 90° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Low Temperature Carbon Steel 90 Deg Short Redius Elbow Exporter in India, 90 Deg Short Redius Elbow Price List in Chennai, Stainless Steel 90 Deg Short Redius Elbow Supplier in India, ANSI/ASME B16.9 90 Deg Short Redius Elbow Exporter in Chennai, Alloy Steel 90 Deg Short Redius Elbow Exporter in Chennai, ASME B16.9 90 Deg Short Redius Elbow in India, MSS-SP-43 90 Deg Short Redius Elbow Size Chart, Alloy Steel ASME B16.25 Price in India, Pipe Fittings 90 Deg Short Redius Elbow Manufacturer Weight Chart, Fitting 90 Deg Short Redius Elbow Supplier in Chennai, Stainless Steel 90 Deg Short Redius Elbow Stockist in India.
Largest 90 Deg Short Redius Elbow Supplier in Chennai, India
Meet Fittings is a leading supplier of 90 Deg Short Redius Elbow in Chennai, India. We offer an extensive range of 90 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Why Choose 90 Deg Short Redius Elbow from Meet Fittings?
Choose 90 Deg Short Redius Elbow from Meet Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Stainless Steel 90 Deg Short Redius Elbow Exporter in India, Carbon Steel 90 Deg Short Redius Elbow in mm, Alloy Steel 90 Deg Short Redius Elbow Manufacturer in Chennai, Super Duplex 90 Deg Short Redius Elbow in Chennai, Nickel Alloy 90 Deg Short Redius Elbow, Low Temperature Carbon Steel 90 Deg Short Redius Elbow Supplier in Chennai, ANSI/ASME B16.9 90 Deg Short Redius Elbow Price List in Chennai, SS 90 Deg Short Redius Elbow Distributor in Chennai, Alloy Steel ASME B16.25 90 Deg Short Redius Elbow Supplier in Chennai, Pipe Fittings 90 Deg Short Redius Elbow Distributor in India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
90° Short Radius Elbows provide several key advantages, including their ability to fit into compact spaces where standard long radius elbows may not be suitable. Their design allows for quick directional changes in piping systems, making them ideal for installations with limited room. Despite their tighter bend, these elbows offer reliable flow control and minimal pressure loss in low-velocity systems. Made from durable materials like stainless steel and alloys, they offer corrosion resistance and long-lasting performance. Widely used in industries such as HVAC, chemical processing, and plumbing, they ensure efficient and effective flow management.
Types of 90 Deg Short Redius Elbow
Are Custom Sizes Available for 90 Deg Short Redius Elbow?
Yes, custom sizes for 90 Deg Short Redius Elbow are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Are Custom Sizes Available for 90 Deg Short Redius Elbow?
| NPS | O.D. D | Center-to-End A |
| 1 | 33.4 | 25 |
| 1 ¼ | 42.2 | 32 |
| 1½ | 48.3 | 38 |
| 2 | 60.3 | 51 |
| 2 ½ | 73 | 64 |
| 3 | 88.9 | 76 |
| 3 ½ | 101.6 | 89 |
| 4 | 114.3 | 102 |
| 5 | 141.3 | 127 |
| 6 | 168.3 | 152 |
| 8 | 219.1 | 203 |
| 10 | 273 | 254 |
| 12 | 323.8 | 305 |
| 14 | 355.6 | 356 |
| 16 | 406.4 | 406 |
| 18 | 457 | 457 |
| 20 | 508 | 508 |
| 22 | 559 | 559 |
| 24 | 610 | 610 |
90 Deg Short Redius Elbow Supplier in Chennai, Stainless Steel 90 Deg Short Redius Elbow Weight Chart, Carbon Steel 90 Deg Short Redius Elbow Exporter in India, Alloy Steel 90 Deg Short Redius Elbow Manufacturer in Chennai, Duplex Steel 90 Deg Short Redius Elbow Price List in Chennai, Super Duplex 90 Deg Short Redius Elbow Sizes in mm, Nickel Alloy 90 Deg Short Redius Elbow Distributor in Chennai, Low Temperature Carbon Steel 90 Deg Short Redius Elbow Distributor in India.
Application Industry of 90 Deg Short Redius Elbow
You’ll find **90° Short Radius Elbow** fittings commonly used in industries like shipbuilding, chemical processing, oil & gas, power generation, and structural engineering. They’re perfect for systems where space is at a premium or where quick changes in flow direction are necessary. These elbows are also utilized in pump and compressor discharge piping, as well as in other applications involving high-velocity fluids. With their robust design and dependable performance under pressure, 90° short radius elbows are crucial for creating compact and efficient piping layouts.
