Alloy 20 Forged Fittings Manufacturer and Supplier in Chennai, India
Based in Chennai, India, we take pride in being a reliable manufacturer and supplier of **Alloy 20 Forged Fittings**. Our products deliver high-performance, corrosion-resistant solutions tailored for the chemical processing, petrochemical, and pharmaceutical sectors. Alloy 20 (UNS N08020) is a specialized nickel-iron-chromium alloy crafted to withstand sulfuric acid and other harsh chemicals. Adhering to international standards like ASTM B462 and ASME B16.11, our forged fittings guarantee outstanding mechanical strength, chemical stability, and precise dimensions, making them perfect for high-pressure applications in corrosive settings.
Table of Contents
UNS N08020 Forged Fittings India, Carpenter® Alloy 20 Forged Fittings Chennai, Alloy 20 High Pressure Forged Fittings Chennai, Alloy 20 Threaded Fittings Chennai, Alloy 20 Socket weld Fittings India, Alloy 20 Socket weld Fittings Chennai, 2.4660 Forged Fittings India, Alloy 20 Forged Fittings India,
Alloy 20 Forged Fittings Specification
| Forged Fittings Specifications | ASTM B462/ ASME SB462 |
|---|---|
| Alloy 20 Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Alloy 20 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Alloy 20 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM B462 Alloy 20 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Alloy 20 Forged Fittings Thread | NPT, BSPT, BSPP |
| Alloy 20 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Nickel Alloy 20 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
**Alloy 20 Forged Fittings** are composed of about 32–38% nickel, 19–21% chromium, 2–3% molybdenum, 3–4% copper, and niobium for stabilization. This unique blend provides exceptional resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. With a tensile strength of around 620 MPa and a yield strength close to 275 MPa, these fittings come in pressure classes of 2000, 3000, and 6000. Our range includes socket weld and threaded elbows, tees, couplings, unions, bushings, and crosses, all designed for leak-proof, high-pressure connections.
Alloy 20 Forged Fittings Chemical Composition
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
Alloy 20 Forged Fittings Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
UNS N08020 Forged Fittings India, Alloy 20 Threaded Fittings Manufacturer in Chennai, Carpenter 20 Forged Cross Trader Chennai, Competitive Price of Alloy 20 Forged Tees Chennai, Ready Stock of NiCr20CuMo Alloy 20 Forged Elbow India, Largest Stockholder of Carpenter® Alloy 20 Forged Fittings in Chennai, Alloy 20 Coupling India, ASTM B462 Socket weld Fittings Manufacturers in Chennai, India.
Largest Alloy 20 Forged Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Alloy 20 Forged Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Alloy 20 Forged Fittings Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Why Choose Alloy 20 Forged Fittings from Meet Fittings?
Alloy 20 Forged Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
ASME SB462 Forged Bushing India, ANSI B16.11 Carpenter 20 Forged Plugs Chennai, Alloy 20 Threaded Fittings Dealer Chennai, Buy Alloy 20 UNS N08020 Full Coupling Chennai, Carpenter® Alloy 20 Forged Cap India, Carpenter 20 Forged Socket weld Fittings Stockist Chennai, Alloy 20 Forged Union India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Alloy 20 Forged Fittings offer exceptional advantages, particularly in challenging industrial environments. They provide outstanding resistance to corrosion, especially against sulfuric, phosphoric, and nitric acids, making them ideal for chemical and pharmaceutical industries. Their excellent mechanical properties ensure high strength, durability, and ease of fabrication. With superior resistance to pitting, crevice corrosion, and stress corrosion cracking, they excel in harsh environments like marine and petrochemical applications. Additionally, their ability to maintain performance across a wide temperature range enhances reliability, ensuring a cost-effective, long-lasting solution for demanding industrial processes.
Manufacturing Standards of Alloy 20 Forged Fittings
| ASTM B462 / B462M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Alloy 20 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Alloy 20 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
ANSI B16.11 Alloy 20 Forged Fittings Forms & Availability
| Products | Size | |
|---|---|---|
| ASTM B462 Alloy 20 90° Elbow | ASTM B462 Alloy 20 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM B462 Alloy 20 Forged Tee | ASTM B462 Alloy 20 Union | |
| ASTM B462 Alloy 20 Forged Cross | ASTM B462 Alloy 20 Insert | |
| ASTM B462 Alloy 20 Screwed Bushing | ASTM B462 Alloy 20 Threaded Pipe Nipple | |
| ASTM B462 Alloy 20 Forged Socket weld Cap | ASTM B462 Alloy 20 Screwed Coupling | |
| ASTM B462 Alloy 20 Forged Plug | ASTM B462 Alloy 20 Street Elbow | |
Types of Alloy 20 Forged Fittings
Are Custom Sizes Available for Alloy 20 Forged Fittings?
Yes, custom sizes for Alloy 20 Forged Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Alloy 2.4660 Threaded Nipple Wholesaler India, Nickel Alloy 20 Half Coupling Chennai, Carpenter Alloy 20 Welding Boss Chennai, Alloy 20 Industrial Forged Fittings Supplier in Chennai, Ready Stock of NiCr20CuMo Alloy 20 Forged Elbow India, Largest Stockholder of Carpenter® Alloy 20 Forged Fittings in Chennai, Alloy 20 Coupling India, ASTM B462 Socket weld Fittings Manufacturers in Chennai, India.
Application Industry of Alloy 20 Forged Fittings
**Alloy 20 Forged Fittings** find extensive use in industries that deal with sulfuric acid, nitric acid, chlorides, and other aggressive chemicals. Common applications include acid production facilities, food and beverage processing, plastic manufacturing, and pharmaceutical plants. These fittings excel in both oxidizing and reducing environments, offering excellent weldability and long-lasting performance. Their robust resistance to chemical attacks and mechanical reliability make Alloy 20 forged fittings the go-to choice for corrosive and high-stress process systems that demand dependable and durable piping components.
