Nestled in Chennai, India, we take pride in being a trusted manufacturer and supplier of **Carbon Steel A105 Forged Fittings**. Our products are known for their durability and ability to withstand high pressure, making them perfect for a variety of industrial applications. ASTM A105 outlines the standard for carbon steel forgings used in piping systems, whether for ambient or high-temperature service. We ensure our forged fittings meet rigorous international standards like ASME B16.11 and MSS-SP-83, which guarantees exceptional mechanical strength, precision, and leak-free performance. These fittings find their place in industries such as oil & gas, petrochemical, power generation, and shipbuilding, thanks to their toughness and reliability.
Carbon Steel A105 Forged Fittings Manufacturer and Supplier in Chennai, India
Table of Contents
Carbon A105 Forged Fittings In India, Carbon Steel A105 High Pressure Forged Fittings Chennai, Carbon Steel A105 Threaded Fittings Chennai, Carbon Steel A105 Socket weld Fittings India, CS Forged Fittings Chennai, Carbon Steel A105 Forged Fittings India, Carbon Steel A105 Socket weld Fittings In India, Carbon Steel ASTM A105 Threaded Fittings Manufacturer in Chennai, India.
Carbon Steel A105 Forged Fittings Specification
| Forged Fittings Specifications | ASTM A105/ ASME SA105 |
|---|---|
| Carbon Steel A105 Forged Fittings size | 1/8” NB to 4” NB (Socket weld & Screwed-Threaded) |
| Carbon Steel A105 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Carbon Steel A105 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A105 Carbon Steel A105 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Carbon Steel A105 Forged Fittings Thread | NPT, BSPT, BSPP |
| Carbon Steel A105 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon A105 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
Chemical Composition of Carbon Steel A105 Buttweld Fittings
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
Mechanical Properties of Carbon Steel A105 Butt weld Pipe Fittings
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
When it comes to composition, **Carbon Steel A105 Forged Fittings** primarily consist of carbon (up to 0.35%), manganese (up to 1.05%), along with trace elements like phosphorus, sulfur, and silicon. They boast a tensile strength of about 485 MPa and a minimum yield strength of 250 MPa, offering good impact resistance and hardness. Available in both threaded and socket weld types, our range includes elbows, tees, couplings, unions, crosses, caps, and plugs—all designed to handle high pressure and moderate temperatures. The A105 material is also well-suited for machining, welding, and heat treatment.
Manufacturing Standards of Carbon Steel A105 Forged Fittings
| ASTM A105 / A105M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel A105 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Carbon Steel A105 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Competitive Price of Carbon Steel A105 Forged Tees India, Ready Stock of Carbon Steel A105 Forged Elbow Chennai, CS A105 Forged Cross Trader Chennai, Carbon Steel A105 Coupling Chennai, Largest Stockholder of Carbon A105 Forged Fittings in India, ASTM A105 Socket weld Fittings Manufacturers in Chennai, Carbon Steel A105 Forged Fittings India.
Carbon Steel A105 Forged Fittings Forms & Availability
| Products | Size | |
|---|---|---|
| ASTM A105 Carbon Steel 90° Elbow | ASTM A105 Carbon Steel 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A105 Carbon Steel Forged Tee | ASTM A105 Carbon Steel Union | |
| ASTM A105 Carbon Steel Forged Cross | ASTM A105 Carbon Steel Insert | |
| ASTM A105 Carbon Steel Screwed Bushing | ASTM A105 Carbon Steel Threaded Pipe Nipple | |
| ASTM A105 Carbon Steel Forged Socket weld Cap | ASTM A105 Carbon Steel Screwed Coupling | |
| ASTM A105 Carbon Steel Forged Plug | ASTM A105 Carbon Steel Street Elbow | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Carbon Steel A105 Forged Fittings offer several advantages, making them ideal for industrial applications. They provide excellent strength and durability, ensuring long service life under high-pressure and high-temperature conditions. Their corrosion resistance makes them suitable for harsh environments, including oil, gas, and chemical industries. With exceptional machinability and weldability, they are easy to install and maintain. These fittings deliver cost-effective performance due to their affordability and extended reliability. Additionally, they comply with international standards, ensuring safety, quality, and compatibility with various piping systems.
Why Choose Carbon Steel A105 Forged Fittings from Meet Fittings?
Carbon Steel A105 Forged Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Carbon Steel A105 Threaded Fittings Dealer In India, Buy Carbon Steel A105 Full Coupling Chennai, ASME SA105 Forged Bushing Chennai, ANSI B16.11 CS A105 Forged Plugs Chennai, Carbon A105 Forged Cap India, CS ASTM A105 Forged Socket weld Fittings Stockist Chennai, Carbon Steel A105 Threaded Nipple Wholesaler India, Carbon A105 Half Coupling In India, Carbon Steel A105 Forged Union Chennai, Carbon Steel A105 Welding Boss Chennai, Carbon Steel A105 Industrial Forged Fittings Supplier in Chennai, India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Types of Carbon Steel A105 Forged Fittings
Are Custom Sizes Available for Carbon Steel A105 Forged Fittings?
Yes, custom sizes for Carbon Steel A105 Forged Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Carbon A105 Forged Fittings In India, Carbon Steel A105 High Pressure Forged Fittings Chennai, Carbon Steel A105 Threaded Fittings Chennai, Carbon Steel A105 Socket weld Fittings India, CS Forged Fittings Chennai, Carbon Steel A105 Forged Fittings India, Carbon Steel A105 Socket weld Fittings In India, Carbon Steel ASTM A105 Threaded Fittings Manufacturer in Chennai, India.
Application Industry of Carbon Steel A105 Forged Fittings
These **Carbon Steel A105 Forged Fittings** are perfect for high-pressure systems that transport steam, oil, gas, water, and other fluids in challenging environments. You’ll find them widely used in refineries, chemical processing plants, power stations, hydraulic systems, and offshore platforms. They deliver outstanding strength, pressure handling capabilities, and precise dimensions, even under tough conditions. Their cost-effectiveness, ease of fabrication, and reliable mechanical performance make them a go-to choice for long-term service in demanding industrial piping networks.
