Inconel 617 Pipe Fittings Manufacturer and Supplier in Chennai, India

Inconel 617 pipe fittings Manufacturer and Supplier in Chennai, India

Inconel 617 Pipe Fittings is manufactured by Meet Fittings, a well-known firm based in Chennai, India. It supplies high-grade components designed to withstand harsh conditions of extreme temperatures and aggressive environments. The pipe fittings are made from Inconel 617, which is an alloy of nickel, chromium, cobalt, and molybdenum. These pipe fittings show excellent resistance to oxidation, carburization, and creep deformation. Meet Fittings offers a complete range of Inconel 617 pipe fittings such as elbows, tees, reducers, crosses, and caps meeting international standards. Fittings find extensive applications across aerospace, chemical process, petrochemical, and power generation industries particularly in high-temperature application.

617 Inconel Alloy Buttweld Tee Dealer In India, ASTM B366 Inconel 617 Pipe Elbow Chennai, 617 Inconel Alloy Butt weld Pipe Fittings Chennai, Inconel Grade 617 Butt weld Pipe Fittings Stockists Chennai, Inconel® 617 Pipe Fittings Suppliers India, Alloy 617 Buttweld Fittings Chennai, Inconel 617 Pipe Fittings India, Distributors of Inconel® Alloy 617 ASME SB366 Buttweld Reducer in Chennai, India.

Inconel 617 Pipe Fittings Specification

Specifications ASTM B366 / ASME SB366

Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79

Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type Seamless / Welded / Fabricated

Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Grade Inconel 617 UNS (N06617), DIN (2.4663)

Inconel 617 Pipe Fittings are made up of about 52% nickel, 22% chromium, 12.5% cobalt, and 9% molybdenum along with tiny amounts of aluminum and carbon. The combination of these elements gives good mechanical strength, oxidation resistance to 1100°C, and excellent metallurgical stability. The alloy retains high tensile strength (more than 550 MPa) and stress rupture resistance, and so it is well suited for parts subjected to thermal cycling as well as to corrosive media.

Inconel 617 Pipe Fittings Chemical Composition

0.05-0.15

1.0 Max

0.015 Max

1.0 Max

20.0-24.0

8.0-10.0

44.5 Min

0.5 Max

0.6 Max

0.8-1.5

0.006 Max

10.0-15.0

3.0 Max

Inconel 617 Pipe Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.1 g/cm3	1411 °C (2571 °F)	Psi – 80,000 , MPa – 550	Psi – 30,000 , MPa – 205	30 %

ASME B16.28 617 Inconel Alloy Butt weld Reducing Tee In India, 617 Inconel® Unequal Cross Exporters Chennai, Nicrofer® 5520 Pipe Fittings Chennai, UNS N06617 Nickel Alloy Butt weld Seamless Pipe Fitting Chennai, 617 Inconel® 45°/90°/180° Butt weld Elbow India, 617 Alloy ANSI B16.9 Short & Long Radius Elbow Chennai, Alloy 617 Equal Tee Wholesaler In India, 617 Inconel Welded Pipe Fittings Suppliers In Chennai, India.

Largest Inconel 617 Pipe Fittings Supplier in Chennai, India

Meet Fittings is a leading supplier of Inconel 617 Pipe Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 617 Pipe Fittings Equivalent Grade

STANDARD	UNS	WNR.
Alloy 617	N06617	2.4663

Why Choose Inconel 617 Pipe Fittings from Meet Fittings?

Inconel 617 Pipe Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Inconel 617 Pipe Fittings Dimensions Chart

NOMINAL PIPE SIZE	ALL FITTINGS	ALL FITTINGS	180 DEG RETURN BENDS	REDUCERS	ELBOWS AND TEES	180 DEG RETURN BENDS	CAPS
NPS	ID at End (1), (3), (4)	OD at Bevel (1), (2)	Centre-to- Centre O	Overall Length H	Centre -to- End Dimension A, B, C, M	Alignment of Ends U	Overall Length E
½ to 2½	0.003	0.006 -0.003	0.025	0.006	0.006	0.003	0.012
3 to 3 ½	0.006	0.006	0.025	0.006	0.006	0.003	0.012
4	0.006	0.006	0.025	0.006	0.006	0.003	0.012
5 to 8	0.006	0.009 -0.006	0.025	0.006	0.006	0.003	0.025
10 to 18	0.012	0.016 -0.012	0.038	0.009	0.009	0.006	0.025
20 to 24	0.019	0.025 -0.019	0.038	0.009	0.009	0.006	0.025
26 to 30	0.019	0.025 -0.019	…	0.019	0.012	…	0.038
32 to 48	0.019	0.025 -0.019	…	0.019	0.019	…

Inconel 617 Pipe Fittings In India, Inconel 617 Butt Weld Fittings Chennai, Inconel 617 Elbow Pipe Fittings Chennai, Inconel 617 Tee Pipe Fittings Chennai, Inconel 617 Cross Pipe Fittings India, Inconel 617 End Cap Pipe Fittings Chennai, 617 Alloy ANSI B16.9 Short & Long Radius Elbow Chennai, Alloy 617 Equal Tee Wholesaler In India, 617 Inconel Welded Pipe Fittings Suppliers In Chennai, India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 617 pipe fittings offer several key advantages, making them ideal for high-temperature and corrosive environments. Their exceptional resistance to oxidation, carburization, and scaling ensures long-term durability, even in extreme conditions. The alloy maintains high strength and excellent creep resistance at temperatures up to 2000°F (1093°C), making it suitable for demanding industrial applications. Inconel 617 also provides superior resistance to high-temperature corrosion, ensuring reliability in the aerospace, power generation, and chemical industries. Additionally, it exhibits excellent weldability and fabricability, offering ease of installation and maintenance in complex systems.

Inconel 617 Pipe Fittings Size Chart

Nominal Pipe Size	45° Elbow		90° Elbow		OD		180° Returns
*(inch.)*	LR		SR	LR			LR
	Radius (inch.)	Center to Face (inch.)	Center to Face (inch.0)	Center to Face (inch.0)	*(inch)*	*(millimeter)*	Back to face (inch.)	Center to Center (inch.)
1/2		5/8	–	1 1/2	0.0840	21.03	1 7/8	2
3/4		7/16	–	1 1/8	1.0050	26.07	1 11/16	2 1/4
1		7/8	1	1 1/2	1.0315	33.04	2 3/16	3
1 1/4		1	1 1/4	1 7/8	1.0660	42.02	2 3/4	3 3/4
1 1/2	3	1 1/8	1 1/2	2 1/4	1.0900	48.03	3 1/4	4 1/2
2	4	1 3/8	2	3	2.0375	60.03	4 3/16	6
2 1/2	5	1 3/4	2 1/2	3 3/4	2.0875	73.00	5 3/16	7 1/2
3	6	2	3	4 1/2	3.0500	88.09	6 1/4	9
3 1/2	7	2 1/4	3 1/2	5 1/4	4.0000	101.06	7 1/4	10 1/2
4	8	2 1/2	4	6	4.0500	114.03	8 1/4	12
5	10	3 1/8	5	7 1/2	5.0563	141.03	10 5/16	15
6	12	3 3/4	6	9	6.0625	168.03	12 5/16	18
8	12	5	8	12	8.0625	219.01	16 5/16	24
10	15	6 1/4	10	15	10.0750	273.01	20 3/8	30
12	18	7 1/2	12	18	12.0750	323.09	24 3/8	36

Types of Inconel 617 Pipe Fittings

Are Custom Sizes Available for Inconel 617 Pipe Fittings?

Yes, custom sizes for Inconel 617 Pipe Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.

617 Inconel Alloy Buttweld Tee Dealer In India, ASTM B366 Inconel 617 Pipe Elbow Chennai, 617 Inconel Alloy Butt weld Pipe Fittings Chennai, Inconel Grade 617 Butt weld Pipe Fittings Stockists Chennai, Inconel® 617 Pipe Fittings Suppliers India, Alloy 617 Buttweld Fittings Chennai, Inconel 617 Pipe Fittings India, Distributors of Inconel® Alloy 617 ASME SB366 Buttweld Reducer in Chennai, India.

Application Industry of Inconel 617 Pipe Fittings

Inconel 617 Pipe Fittings have extensive use in applications like gas turbines, heat exchangers, reformers, furnace equipment, and high-temperature chemical reactors. Their unparalleled resistance to high-temperature corrosion and resistance to high mechanical stress guarantee successful performance under extreme conditions. Inconel 617 Pipe Fittings ensure secure, leak-proof joints and long service life, minimizing the need for frequent maintenance. Due to their high strength, good oxidation resistance, and heat stability, Inconel 617 pipe fittings are a choice selection for critical service in harsh industrial applications.
