Stainless Steel 316 / 316L Buttweld Fittings Manufacturer and Supplier in Chennai, India
Meet Fittings, based in Chennai, India, is a well-known producer and supplier of *Stainless Steel 316 / 316L Buttweld Fittings*, which provide high-quality solutions for corrosive and high-pressure working conditions. These fittings are made from top-quality austenitic stainless steel renowned for its superior corrosion resistance, particularly in environments rich in chloride. Meet Fittings offers a broad spectrum of buttweld fittings including elbows, tees, reducers, caps, and crosses in 316 and its low-carbon version 316L. Keeping in mind durability, accuracy in dimensions, and with adherence to international standards, the company serves sectors including pharmaceuticals, petrochemicals, marine, food processing, and power generation.
Table of Contents
Stainless Steel 316 Pipe Elbow In India, Stainless Steel 316L Pipe Fittings Chennai, SS 316 Buttweld Elbow Chennai, Stainless Steel S31600 Seamless Fittings Exporter Chennai, Stainless Steel 1.4301 Butt Weld Pipe Fittings in India, Stainless Steel 316L Two Joint Pipe Fittings Chennai, 316 Stainless Steel Welded Fittings Manufacturers in India, Stainless Steel 316L Buttweld Fittings In India, ASTM A403 WP3 316 Stainless Steel Buttweld Fittings Supplier in Chennai, India.
Stainless Steel 316 / 316L Buttweld Fittings Specification
| Specifications | ASTM A403 / ASME SA403 |
|---|---|
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | Seamless / Welded / Fabricated |
Stainless steel 316 and 316L buttweld fittings, with low carbon content, are made of austenitic alloys mainly of iron, chromium (16-18%), nickel (10-14%) and molybdenum (2-3%) not 316L ( 0). .03% max) sense 316 (0.08% max). This design provides excellent corrosion resistance, especially in chloride environments. Mechanical properties include 520 MPa tensile strength, 205 MPa yield strength and 40-50% elongation. The material exhibits excellent weldability, formability and hardness even at cryogenic temperatures, making it suitable for harsh environments in the chemical, petrochemical and marine industries
Stainless Steel 316 / 316L Buttweld Fittings Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316 | min. | – | – | – | – | 16.0 | 2.0-3.0 | 10.0 | – | |
| max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | – | ||
| 316L | min. | – | – | – | – | – | 16.0 | 2.0-3.0 | 10.0 | – |
| max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | – | ||
Stainless Steel 316 / 316L Buttweld Fittings Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
ASTM A403 Stainless Steel 316 Buttweld Fittings Cross in India, Stainless Steel 1.4301 Buttweld Pipe Fittings Chennai, SS 316L Butt Weld Pipe Cap Chennai, Stainless Steel 316 Eccentric Reducer Chennai, Stainless Steel 316 Equal Tee India, 316 Stainless Steel Reducer in Chennai, Stainless Steel 316L SR Elbow Exporter in India,
Largest Stainless Steel 316 / 316L Buttweld Fittings Supplier in Chennai, India
Stainless Steel 316 / 316L Buttweld Fittings are mainly made up of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%) content, which increases corrosion resistance especially against chlorides and acidic media. 316L has a lower carbon content (max 0.03%) than 316 (max 0.08%), lowering the possibility of carbide precipitation upon welding and enhancing weldability. These fittings offer superior mechanical strength with a tensile strength of around 515 MPa and yield strength of 205 MPa, as well as superior ductility and toughness in cryogenic and high-temperature conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Stainless Steel 316 / 316L Buttweld Fittings Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 316 Fittings | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L Fittings | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Why Choose Stainless Steel 316 / 316L Buttweld Fittings from Meet Fittings?
Stainless Steel 316 / 316L Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
UNS S31603 Stub End Uk, ANSI B16.9 Stainless Steel 316L Pipe Fittings Chennai, Stainless Steel 316 Pipe Bend Stockist in Chennai, Stainless Steel 316L Pipe Nipple Manufacturer & Exporter in Chennai, Stainless Steel 1.4301 Butt Weld Pipe Fittings in India, Stainless Steel 316 Pipe Two Joint Pipe Fittings Chennai, 316L Stainless Steel Pipe Welded Fittings Manufacturers in India, Stainless Steel 316 Pipe Butt weld Fittings In India, ASTM A403 Stainless Steel 316L Pipe Butt Weld Fittings Supplier in Chennai, India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Stainless steel 316/316L Buttweld Fittings provide excellent corrosion resistance, especially in harsh environments such as the marine and chemical industry, and the presence of molybdenum provides superior strength, durability and superior heat resistance against, making it ideal for important projects. The lower carbon content of 316L reduces the risk of sensitivity and intergranular corrosion, and enhances weldability. These materials are highly resistant to pitting and cravis corrosion, providing long service life. In addition, it is inert, easy to maintain, and provides flexible and leak-proof connections to plumbing systems.
Types of Stainless Steel 316 / 316L Buttweld Fittings
Stainless Steel 316 / 316L Buttweld Fittings Dimensions Chart
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
|---|---|---|---|---|---|---|---|---|
| (inches) | (mm) | (inches) | Length (inches) | Center to End (inches) | Center to End (inches) | Lap Diameter (inches) | Long Length (inches) | Short Length (inches) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Are Custom Sizes Available for Stainless Steel 316 / 316L Buttweld Fittings?
Yes, custom sizes for Stainless Steel 316 / 316L Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
ASTM A403 Stainless Steel 316 Butt Weld Cross in India, Stainless Steel 1.4301 Buttweld Pipe Fittings Chennai, SS 316L Butt Weld Pipe Cap Chennai, Stainless Steel 316 Eccentric Reducer Chennai, Stainless Steel 316L Equal Tee India, 316 Stainless Steel ReducKingdomer in Chennai, SS 316L SR Elbow Exporter in India,
Application Industry of Stainless Steel 316 / 316L Buttweld Fittings
Stainless Steel 316 / 316L Buttweld Fittings find extensive applications in those industries where corrosion resistance, particularly in chlorides, is of utmost importance. Uses cover chemical processing, marine piping systems, pharmaceutical production lines, food and beverage equipment, heat exchangers, and seawater desalination plants. 316L is best for welded applications because of its resistance to intergranular corrosion. These buttweld fittings offer leak-proof joints, resist high-pressure conditions, and support long service life even in hostile and sanitary environments. Their superior hygienic characteristics also make them suitable in applications requiring constant cleaning and sterilization.
